VERILOG DATATYPES AND OPERATORS - SYNTAX - EXAMPLES

DATATYPES:
          The datatype denotes the type of the data assigned & processed by the variable. But in Verilog it exactly specifies the output type, such as a storage or non-storage type.
          The different datatypes in verilog are as follows
NETS
wire
Establishes connectivity, with no logical behavior or functionality implied.  (within non-procedural statements only)
tri
Establishes connectivity, with no logical behavior or functionality implied. This type of net has the same functionality as wire, but is identified distinctively to indicate that it will be three-stated in hardware.
wand
A net that is connected to the output of multiple primitives. It models the hardware implementation of a wired-AND, e.g., open collector technology.
wor
A net that is connected to the output of multiple primitives. It models the hardware implementation of a wired-OR, e.g., emitter coupled logic.
supply0
A global net that is connected to the circuit ground.
supply1
A global net that is connected to the power supply.
tri0
A net that is connected to ground by a resistive pull-down connection.
tri1
A net that is connected to the power supply by a resistive pull-up connection.
trireg
A net that models the charge stored on a physical net.

REGISTERS
reg
Register variables are assigned values by procedural statements within an always or initial block. REG variables can only be output.

Register variables hold their value until an assignment statement changes them. The following are predefined register types: reg, integer (32 bit, 2s complement), real (double precision 64bit), realtime, and time (for time related functions).

MEMORIES
       Verilog does not have separate datatype for memory array. But can be used from other data type reg
SYNTAX:      reg  [word_size]   <variable>[array_size];

STRINGS
       Verilog does not have a distinct data type for strings. Instead, a string must be stored within a properly sized register by a procedural assignment statement. A properly sized reg (array) has 8 bits of storage for each character of the string that it is to hold.

SYNTAX:      reg [8*num_char-1: 0] string_holder;

CONSTANTS
A constant in Verilog is declared with the keyword parameter, which declares and as- signs value to the constant. The value of a constant may not be changed during simulation. Constant expressions may be used in the declaration of the value of a constant.
SYNTAX:     parameter <variable> = <value>;

EXAMPLES
wire out1;
"out1" is a wire that only outputs
reg out2;
 "out2" is a register; it stores and outputs a value
reg [7:0] out3;
"out3" is a 8-bit register
reg [15:0] out4[7:0];
 "out4" is a 8-bit register array from 0 to 7
 Scope of a variable:

          The same net type is not referenced exactly the same within module, task, function. The flow is as given in the figure,

 OPERATORS:
          Operators in Verilog are the same as they are in other programming languages. They take two values and compare (or otherwise operate on) them to yield a third result. The following table briefs the operator and its examples.
Operator
Argument
Result
Arithmetic
Pair of operands
Binary word
Bitwise
Pair of operands
Binary word
Reduction
Single operand
Bit
Logical
Pair of operands
Boolean value
Relational
Pair of operands
Boolean value
Shift
Single operand
Binary word
Conditional
Three operands
Expression

OPERATOR TYPE
OPERATOR SYMBOL
OPERATION PERFORMED
EXAMPLE


Arithmetic
*
Multiply
x= a*b

/
Division
x= a/b

+
Add
x= a+b

-
Subtract
x= a-b

%
Modulus
x= a%b

+
Unary plus
x= a+b

-
Unary minus
x= a-b

Logical
!
Logical negation
!a

&&
Logical and
a && b

||
Logical or
a || b

Relational
Greater than
a>b

Less than
a<b

>=
Greater than or equal
a>=b

<=
Less than or equal
a<=b

Equality
==
Equality
a == b

!=
inequality
a != b

===
CASE equality
a === b

(includes x,z in bit-by-bit basis)

!==
CASE inequality
a !== b

(includes x,z in bit-by-bit basis)

Reduction
~
Bitwise negation
x= ~a

~&
nand
~&a

|
or
x= |a

~|
nor
x= ~|a

^
xor
x= ^a

^~
xnor
x= ^~a

~^
xnor
x= ~^a

Shift
>>
Right shift
x= a>> n

<<
Left shift
x= a<< n

Concatenation
{ }
Concatenation
x= {a,b,n}

x={a[3:0],b,a[7:4]}

Conditional
?
conditional
x= a<b?1:0


OPERATOR PRECEDENCE
Sign complement
HIGHEST
Multiplication Division Modulus
|
|
|
|
|
|
V
Addition Subtraction
Shift
Relational
Reduction
Logical
Conditional
LOWEST
